BLUELIFT SA 26
Performance data given are maximum values. Exact dimensions and weights are depending on the carrier chassis.
BLUELIFT SA 26
Working height
26 m
Lifting height
24 m
Lateral outreach
14,5 m
Total height
1,98 m
Total width
0,99 m
Total length
4,91 m
Basket load
250 kg
Basket size
1,3m x 0,7m x 1,1m
Range of rotation
340°
Overall weight
3350 kg
Ground pressure in working position
22,71 kN
Ground pressure under crawlers
46,55 kN/m2
Travel speed
1,5 km/h
Gradeability
28%
Jacking widths
4,44 m
Jacking length
4,30 m
Combustion engine
Honda iGX
Electric motor
230V - 2,2 kW
